Description

Typical Type: 270W

Max Power (Pmax): 270

Max Power Voltage (Vmp): 30.96

Max Power Current ( Imp): 8.07

Open Circuit Voltage (Voc): 37.92

Short Circuit Current (Isc): 8.62

Cell Efficiency (%): 17.96

Module Efficiency: 15.37

Max System Voltage: DC1000V

Maximum Series Fuse Rating: 15A

Mechanical Data

Dimensions: 1640 x 992 x 40/ 35MM

Weight: 18 kgs

Front Glass: 3.2 mm tempered glass

Output Cables: 4 mm2 symmetrical, lengths 900mm

Connectors: MC4 compatible IP67

Cell Type: Mono Crystalline Silicon 156mm x 156mm

Number of Cells: 60 cells in series

Temperature Characteristics

Temp. Coeff of Isc (TK Isc): 0.037% / ̊C

Temp. Coeff of Voc (TK Voc): (-0.34%) / ̊C

Temp. Coeff of Pmax (TK Pmax): (-0.048%) / ̊C

Operating Temperature: (-40% -+ 85%) / ̊C

Normal Operating Cell Temperature: 45± 2%

Packing Configuration

Container: 40’HQ

Pieces per pallet: 56

Pallets per container: 14

Pieces per container: 784

Test Certifications and Warranty

Standard Tests: IEC 61215, IEC 61730

System certs: ISO 9001, ISO14001

Certification: TUV, CE ,MCS, PV CYCLE, CHUBB Extreme wind and snow loads testing Withstand extreme wind (2400 Pascal) and snow loads (5400 Pascal)

Positive tolerance 0 -+ 3%

Junction Box ≥IP65
